Parameter
|
Units
|
Minimum
|
Maximum
|
Comment
|
Path length (Flange to flange)
|
m
|
0.5
|
20 (12 Double Pass)
|
Flange to Flange Separation
|
Measuring range
|
mg/m3
|
0.0
|
1000.0
|
User Selectable
|
Accuracy
|
%
|
-2
|
+2
|
Relative to the maximum range
|
Resolution
|
mg/m3
|
|
0.1
|
Display resolution
|
Voltage
|
V DC
|
+24
|
+24
|
Optical 90-260 V AC PSU Available
|
Operating wavelength
|
nm
|
510
|
540
|
Green LED
|
Serial communications
|
|
|
|
Modbus, Internal USB, ProfiBus, DeciceNet, Ethernet
|
Analog outputs
|
mA
|
4.0
|
20.0
|
isolated and scalable
|
Relay contacts
|
A
|
0
|
3
|
@30 V DC (level alarm and service alarm)
|
Ingress protection - TX/RX heads
|
|
IP 65
|
|
For external use
|
Materials - TX/RX reflector
|
|
|
|
Cast aluminium, Polycarbonate measurement head
|
Dimensions
|
|
|
|
250 X 200 X 100 mm
|
